Page 19 MEAN WELL INDUSTRIAL POWER SUPPLY CATALOG

Enclosed-PFC 150~300W Programmable Power Lite

Features
• Universal AC input / Full range
• Built-in active PFC function
• Protections:
Short circuit / Overload / Over voltage / Over temperature
• Output voltage programmable
• Forced air cooling by built-in DC fan (except for SPV-150)
• 3 years warranty
SPV-300 SPV-150

General Specification (Please refer to www.meanwell.com for detail spec.)

Model No. SPV-150 SPV-300
AC input voltage range 88~264VAC; 124~370VDC
AC inrush current (max.) Cold start, 45A at 230VAC

Vo: -15%~+10% by potentiometer or to 20%~110% of rated output voltage
DC adjustment range
by 1~5.5VDC external control signal

Overload Range 105%~150% 105%~135%
protection Type constant current limiting, auto-recovery

Over voltage Range 115%~140%
protection Type shut down O/P voltage, re-power on to recover
Withstand voltage I/P - O/P: 3kVAC, I/P-FG: 2kVAC, O/P-FG: 0.5kVAC
Working temperature -20~+65°C
Safety standards UL62368-1, TUV EN62368-1, EAC TP TC 004 approved
EMC standards EN55032 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EAC TP TC 020
Dimension (LxWxH) (mm) 215x 115x 50
Case No. 912L 912G
Packing 1.1kg ; 12pcs / 14kg / 0.92CUFT

150W SPV-150 300W SPV-300
Model No. Output Tol. R&N Effi. Model No. Output Tol. R&N Effi.

SPV-150-12 12V, 0~12.5A ±1% 150mV 82% SPV-300-12 12V, 0~25A ±1% 150mV 83.5%

SPV-150-24 24V, 0~6.25A ±1% 150mV 83% SPV-300-24 24V, 0~12.5A ±1% 150mV 85.0%

SPV-150-48 48V, 0~3.125A ±1% 240mV 83% SPV-300-48 48V, 0~6.25A ±1% 240mV 86.5%

►►Output Voltage Programmable for SPV series

Best products also need best service.
We have authorized distributors all over the world. They have
sufficient stock for your prompt delivery. Also, they can offer
you technical support & RMA services. Please contact your
local distributors for more product information. You can also 1~5.5V
contact us at info@meanwell.com for information of your local
distributors.

16
