Page 25 MEAN WELL INDUSTRIAL POWER SUPPLY CATALOG

Enclosed-PFC 3200W Programmable & Intelligent High Power

Features
• Universal AC Input / Full range
• Built-in active PFC function
NEW
• High efficiency, up to 94.5% (48VDC)
• High power density 37W/in 3
• Air cooling by built-in DC fan
• PV (Programmable voltage)and PC (Programmable
constant current) functions
• Active current sharing, up to 16000W (5 units) in parallel
• I C interface, support optional PMBus & CANBus protocol
2
• Protections: Short circuit / Overload /
Over voltage / Over temperature
• Optional conformal coating
• 5 years warranty
Order Information

DPU-3200- 24
{ Blank: Standard
Communication protocol option PM: PMBus
Output voltage (24V/48V) CAN: CANBus
Output wattage
Series name

General Specification (Please refer to www.meanwell.com for detail spec.)

Model No. DPU-3200

AC input voltage range 90-264VAC, 127~370VDC

AC inrush current (max.) 17A/230VAC, COLD START
DC adjustment range 24V: 23.5-30V; 48V: 47.5-58.8V

Over voltage protection 24V: 31.5-37.5V; 48V: 63-75V
Withstand voltage I/P-O/P: 3KVAC; I/P-FG: 2KVAC; O/P-FG: 1.5KVAC

Working temperature -30-+70°C (refer to output derating curve)
Safety standards UL62368-1, TUV EN62368-1, EAC TP TC 004 approved

Compliance with EN55032 (CISPR32) Conduction Class B, Radiation Class A; EN61000-3-2,3, EN61000-4-2,3,4,6,8,11,
EMC standards
EN61000-6-2, EAC TP TC 020
Connection Bus Bar
Dimension (LxWxH) (mm) 325.8x 107x 41
Case No. 256

Model No. Output Efficiency
Best products also need best service.
DPU-3200-24 24V, 0-110A 93.5% We have authorized distributors all over the world. They have
sufficient stock for your prompt delivery. Also, they can offer
DPU-3200-48 48V, 0-55A 94.5% you technical support & RMA services. Please contact your
