Medical Adaptor 90~120W Desktop Type

GSM90A GSM90B GSM120A GSM120B
Features
• Universal AC input / Full range • High efficiency up to 91.5%
• Medical safety approved (2xMOPP) • A-Type: Class I (with earth Pin);
• Suitable for BF application with appropriate system consideration (B-Type only) B-Type: Class II (without earth Pin)
• Extremely low leakage current • Protections: Short circuit / Overload / Over voltage / Over temp.
• No load power consumption <0.15W • Fully enclosed plastic case
• Energy efficiency Level VI • LED indicator for power on
• Comply with EISA 2007/DoE, NRCan, AU/NZ MEPS, • Optional lock type DC plug
EU ErP and meet CoC Version 5 • 3 years warranty
• Built-in active PFC function
General Specification (Please refer to www.meanwell.com for detail spec.) (B-Type only)
Order No. GSM90A GSM90B GSM120A GSM120B

AC input voltage range 80~264VAC; 113~370VDC
Leakage current <100μA
AC inrush current (max.) Cold start, 60A at 230VAC Cold start, 70A at 230VAC
Overload Range 110%~150% rated output power 105%~160% rated output power
protection Type Hiccup mode, auto-recovery
Over voltage Range 105%~135% rated output voltage
protection Type Shut down o/p voltage, re-power on to recover
Setup, rise, hold up time 1000ms, 50ms, 40ms 1000ms, 50ms, 30ms 1500ms, 30ms, 40ms
Withstand voltage A-Type: I/P-O/P: 4kVAC, I/P-FG: 2kVAC, O/P-FG: Short A-Type: I/P-O/P: 4kVAC, I/P-FG: 2kVAC, O/P-FG:0.5kVAC,
B-Type: I/P-O/P: 4kVAC B-Type: I/P-O/P: 4kVAC
Working temperature -30~+70°C (refer to output derating curve)
A-Type: ANSI/AAMI ES60601-1, CAN/CSA-C22, TUV EN60601-1, EAC TP TC 040 approved
Safety standards B-Type: ANSI/AAMI ES60601-1, CAN/CSA-C22, ES60601-1-11, TUV EN60601-1, EN60601-1-11, EAC TP TC 004 approved

EMC standards EN55011 class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, EN61204-3, EN60601-1-2 medical level, FCC Part 15 class B,
EAC TP TC 020
Length of output cable 100cm of UL1185, 14AWG for 12~15V; 100cm of UL2464, 18AWGx4C for 12V;
120cm of UL1185, 16AWG for 19~48V 120cm of UL2464, 18AWGx4C for 15~48V
Standard DC plug P1M: 2.5øx5.5øx11mm/c+, tuning fork type R7B: Power DIN 4P with lock type
(refer to page 59 for DC plug list)
Dimension (LxWxH)(mm) 145x 60x 32 167x 67x 35

Desktop (IEC 320-C14 / Class I) ─ 90W Desktop (IEC 320-C8 / Class II) ─ 90W
Order No. Output Tol. R&N Effi. Order No. Output Tol. R&N Effi.
GSM90A12-P1M 12V, 0~6.67A ±5% 120mV 88.0% GSM90B12-P1M 12V, 0~6.67A ±5% 120mV 88.0%
GSM90A15-P1M 15V, 0~6.00A ±5% 120mV 89.0% GSM90B15-P1M 15V, 0~6.00A ±5% 120mV 89.0%
GSM90A19-P1M 19V, 0~4.74A ±4% 120mV 89.0% GSM90B19-P1M 19V, 0~4.74A ±4% 120mV 89.0%
GSM90A24-P1M 24V, 0~3.75A ±3% 180mV 90.0% GSM90B24-P1M 24V, 0~3.75A ±3% 180mV 90.0%
GSM90A48-P1M 48V, 0~1.87A ±2.5% 200mV 91.0% GSM90B48-P1M 48V, 0~1.87A ±2.5% 200mV 91.0%

Desktop (IEC 320-C14 / Class I) ─ 120W Desktop (IEC 320-C8 / Class II) ─ 120W
Order No. Output Tol. R&N Effi. Order No. Output Tol. R&N Effi.
GSM120A12-R7B 12V, 0~8.50A ±5% 100mV 88.0% GSM120B12-R7B 12V, 0~8.50A ±5% 100mV 88.0%

GSM120A15-R7B 15V, 0~7.00A ±5% 120mV 89.0% GSM120B15-R7B 15V, 0~7.00A ±5% 120mV 89.0%
GSM120A20-R7B 20V, 0~6.00A ±4% 180mV 89.0% GSM120B20-R7B 20V, 0~6.00A ±4% 150mV 89.0%
GSM120A24-R7B 24V, 0~5.00A ±3% 180mV 90.0% GSM120B24-R7B 24V, 0~5.00A ±3% 180mV 90.0%
GSM120A48-R7B 48V, 0~2.50A ±2.5% 200mV 91.5% GSM120B48-R7B 48V, 0~2.50A ±2.5% 200mV 91.5%
