Page 68 MEAN WELL INDUSTRIAL POWER SUPPLY CATALOG

Medical Adaptor 12~60W Interchangeable Type

Features
• Interchangeable AC plugs (plug kit sold separately)
• Medical safety approved (2xMOPP)
• Suitable for BF application with appropriate system consideration
• No load power consumption <0.075W
(<0.1W for GEM12I18V/48V and GEM30I/40I,<0.15W for GEM60I)
• Energy efficiency Level VI
• Comply with EISA 2007/DoE and EU ErP
• Class II power (without earth pin)
• Protections: Short circuit / Overload / Over voltage
GEM12I 73.9x 39x 48.5 mm • Extremely low leakage current
GEM18I/30I/40I 75.5x 39.1x 56.2 mm • Fully enclosed plastic case
GEM60I 75.5x 39.1x 56.2 mm
• 3 years warranty
General Specification (Please refer to www.meanwell.com for detail spec.)
Order No. GEM12I GEM18I GEM30I GEM40I GEM60I
AC input voltage range 80~264VAC; 113~370VDC
Leakage current <100μA
Withstand voltage I/P-O/P: 5656VDC, 1 minute
Working temperature -20~+70°C -20~+50°C -25~+70°C (refer to output derating curve) -30~+70°C
Safety standards ANSI/AAMI ES60601-1/60601-1-11, CAN/CSA-C22, TUV EN60601-1/60601-1-11 approved (GEM18I TUV&UL60601-1 only)
EMC standards EN55011 Class B, EN61000-3-2,3, EN61000-4-2,3,4,5,6,8,11, FCC part18 class B
5~7.5V: 100cm 5~12V: 100cm
Length of output cable 9V: 120cm 5~12V: 100cm 15~24V: 150cm 5~15V: 100cm 5~18V: 100cm
12~48V: 150cm 15~48V: 150cm 48V: 180cm 18~48V: 150cm 24~48V: 150cm
Standard DC plug P1J: 2.1øx5.5øx11mm/C+, turning fork type (refer to page 59 for DC plug list)
Wall-mounted(Interchangeable Type)─12W (main body) Output Tol. R&N Effi.
Order No.
Order No. GEM30I12-P1J 12V, 0~2.50A ±3% 100mV 87%
(main body) Output Tol. R&N Effi.
GEM12I05-P1JUSB 5V, 0~2.4A ±5% 60mV 80% GEM30I15-P1J 15V, 0~2.00A ±3% 100mV 87%
100mV
88%
18V, 0~1.66A
±2%
GEM12I05-P1J 5V, 0~2.4A ±5% 60mV 80% GEM30I18-P1J 24V, 0~1.25A ±2% 100mV 88.5%
GEM12I07-P1J 7.5V, 0~1.6A ±5% 60mV 82% GEM30I24-P1J 48V, 0~0.62A ±2% 100mV 90%
GEM30I48-P1J
GEM12I09-P1J 9V, 0~1.33A ±4% 60mV 82%
GEM12I12-P1J 12V, 0~1A ±3% 80mV 82.5% Wall-mounted(Interchangeable Type)─40W
GEM12I15-P1J 15V, 0~0.8A ±3% 80mV 84% Order No.
GEM12I18-P1J 18V, 0~0.66A ±3% 80mV 84% (main body) Output Tol. R&N Effi.
GEM12I24-P1J 24V, 0~0.5A ±2% 80mV 85% GEM40I05-P1J 5V, 0~5.00A ±5% 100mV 84%
GEM12I48-P1J 48V, 0~0.25A ±2% 100mV 87% GEM40I09-P1J 9V, 0~4.00A ±5% 100mV 87%
Wall-mounted(Interchangeable Type)─18W GEM40I12-P1J 12V, 0~3.33A ±3% 100mV 88%
Order No. GEM40I15-P1J 15V, 0~2.66A ±3% 120mV 88%
(main body) Output Tol. R&N Effi. GEM40I18-P1J 18V, 0~2.22A ±2% 120mV 88%
GEM18I05-P1J 5V, 0~3.00A ±5% 60mV 80% GEM40I24-P1J 24V, 0~1.67A ±2% 120mV 89%
GEM18I09-P1J 9V, 0~2.00A ±5% 60mV 84% GEM40I48-P1J 48V, 0~0.80A ±2% 200mV 90.5%
GEM18I12-P1J 12V, 0~1.50A ±3% 80mV 84%
GEM18I15-P1J 15V, 0~1.20A ±3% 80mV 84% Wall-mounted(Interchangeable Type)─60W
GEM18I18-P1J 18V, 0~1.00A ±2% 80mV 84% Order No. Output Tol. R&N Effi.
GEM18I24-P1J 24V, 0~0.75A ±2% 80mV 85% (main body)
GEM18I48-P1J 48V, 0~0.38A ±2% 80mV 87% GEM60I05-P1J 5V, 0~6.00A ±5% 100mV 80%
GEM60I07-P1J 7.5V, 0~6.00A ±5% 100mV 85%
Wall-mounted(Interchangeable Type)─30W GEM60I09-P1J 9V, 0~5.50A ±5% 100mV 87%
Order No. GEM60I12-P1J 12V, 0~5.00A ±5% 100mV 88%
(main body) Output Tol. R&N Effi. GEM60I15-P1J 15V, 0~4.00A ±5% 120mV 88%
GEM30I05-P1J 5V, 0~4.00A ±5% 100mV 82% GEM60I18-P1J 18V, 0~3.33A ±3% 120mV 88%
GEM30I07-P1J 7.5V, 0~3.33A ±5% 100mV 86% GEM60I24-P1J 24V, 0~2.50A ±3% 120mV 88%
GEM30I09-P1J 9V, 0~3.33A ±5% 100mV 87% GEM60I48-P1J 48V, 0~1.25A ±3% 150mV 90%
Interchangeable AC Plug Specifically for GEM12/18/30/40I/60I
AC Plug Type and Order No.
AC Plug-AU2 AC Plug-UK2 AC Plug-EU2 AC Plug-US2 AC Plug-MIX2

Australian Type U.K. Type European Type U.S. Type Mixed Four Type
The main body unit and AC plug should be ordered seperately. The main body needs to be used along with any one of the AC plug.
65
